Alan 9001 Amateur Radio Mobile

Frequency coverage

28.0000–29.6999 MHz Reference

Bands

Band A: 28.0000–28.4999 MHz; Band B: 28.5000–28.9999 MHz; Band C: 29.0000–29.4999 MHz; Band D: 29.5000–29.6999 MHz Reference

Modes

CW, USB, LSB, AM, FM Reference

RF output power

CW: 25 W nominal; USB/LSB: 25 W PEP nominal; AM/FM: 10 W nominal Reference

Audio output power

4.5 W nominal Reference

Power requirement

13.8 V DC nominal, negative ground Reference

Frequency stability

±300 Hz nominal at 25°C, 5 minutes after power-on Reference

Dimensions

200(W) × 265(D) × 60(H) mm Reference

Antenna impedance

50 ohms Reference

Antenna connector

SO-239 female RF connector Reference

Sensitivity

AM: 1 µV nominal; CW/USB/LSB: 0.3 µV nominal; FM: 1 µV nominal Reference

Specifications may vary by revision or market. Use linked manufacturer references when available and confirm critical details before purchase.
